Infographic: RSAF Singapore Airshow 2022 Aerial Display
11 February 2022
This article has been migrated from an earlier version of the site and may display formatting inconsistencies.

The show begins with the F-16C entering from the middle right of the show centre and pulling up vertically. At about 90deg nose-up, the F-16C will roll to its right and re-position 45deg to the show centre. At the start of the descend, the F-16C will be releasing flares and perform a 4-6 Gs pull to level off. Just prior to show centre, the F16C will make a hard turn to the left.

The F-16C will fly across show centre from right to left in an inverted position.

The F-16C will enter show centre from the front left (about 45deg), turn away at show centre while releasing flares before flying off across show centre from right to left.

The F-16C will showcase its slow speed manoeuvrability of the aircraft by flying at the slowest possible speed (120 knots). At the show centre, the F-16C will select afterburners to perform an aggressive climb out vertically.

The F-16C performs a precise four-point roll on its portside by pausing exactly at the 90-degree, 180-degree, 270-degree and 360-degree points for one second.

The F-16C will first pull up into the vertical for a loop, twisting while levelling-off and thereafter pull to 9Gs in a 360-degree level turn.

The F-16C will first pull up into the vertical for a loop, twisting while levelling-off and thereafter pull to 9Gs in a 360-degree level turn.

The F-16Cs executes four full 360-degree rolls along its longitudinal axis, from left to right, creating a spiraling effect.

The F-16C rolls 90 degrees on its side displaying the top of the aircraft to the crowd as it flies past the crowd from right to left.

The F-16C will perform a vertical spiral climb, with a column of flares to close the show.

The show begins with the AH-64D Apache helicopters flying towards the show centre in close formation. The two helicopters then make a 90-degree turn into each other to cross paths in front of the show centre.

Each AH-64D pulls up to a 45-degree pitch, rolls 90 degrees to its side, and enters a 30-degree dive to effect a 180-degree turn. This is executed in a synchronised manner with one AH-64D on each side of the show centre.

The AH-64Ds will come nose to nose in this close proximity pass.

The AH-64D will rapidly climb at maximum power to higher altitude while making a 180-degree turn. This will allow him to provide cover for his wingman who remains at low altitude for attacks.

The AH-64D pulls up to a 60-degree climb as it approaches the show centre. At the apex of the climb, it executes a rapid turn at zero airspeed, and enters a steep dive away from the show centre to showcase its manoeuvrability.

The AH-64D will execute a steep spiral descent down in front of the show centre.

The AH-64D will pitch up 60 degrees, roll 90 degrees to its side, and execute a 360-degree turn before exiting the show centre.

In this synchronised manoeuvre, the AH-64Ds will pull up into a steep climb, tip over at the apex, and enter into a steep dive to form the twin peaks.

The AH-64Ds will fly towards the show centre in close formation.

The AH-64D will track back towards the show centre in a backwards flight.

The AH-64D will initiate a backward climb before pitching back down into forward flight.

In this closing manoeuvre, one AH-64D will bow in front of the show centre while the other AH-64D pitches up in close proximity to execute the tail sweep.
